IntroductionFor Route Segment, PANS-AIM requires as part of the minimum data set information about the navigation specification and required navigation performance.For the AIP data set PANS-AIM requires 2 properties related to Performance Based Navigation (PBN) of a route segment. 'Navigation specification'Designation of the navigation specification(s) applicable to a specified segment(s) - There are two kinds of navigation specifications:Required navigation performance (RNP) specification.

A navigation specification based on area navigation that includes the requirement for performance monitoring and alerting, designated by the prefix RNP, e.g. RNP 4, RNP APCH.Area navigation (RNAV) specification. A navigation specification based on area navigation that does not include the requirement for performance monitoring and alerting, designated by the prefix RNAV, e.g. AIXM 5.1.1 provides two attributes regarding navigation specifications for a RouteSegment.

Both seem to be insufficient to code the designation of the PBN specification. navigationType is basically used to encode if the route is ' CONV 'or ' RNAV', but is not intended to code the PBN specification. Although, ' OTHER' could be used to define PBN Navigation Specifications, e.g. ' RNAV 5' or 'RNP 4'. requiredNavigationPerformance is intended to code RNP values (any two-digit value with one decimal is allowed).Status: for AIXM 5.2 see CCBWorkaround for AIXM5.1.1, until the open PBN issue are clarified within the AIXM CCB, the following coding is proposed:.

Capture one express. The Result was PBN SDM PBN Workshop 7 PBN Concept replaced RNP Concept Publication of Doc 9613, PBN Manual in 2008 Resolution of ICAO’s 36 th Assembly Reiterated at 37 th Assembly Manual updated in 2013. 1 ICAO DOC 9613 Performance-Based Navigation Manual Volume II. 9750-AN/963 2013 – 2028 Global Air Navigation Plan Fourth Edition.

Use the value ' OTHER' for the attribute RouteSegment.navigationType e.g. ' OTHER:RNAV5 ' or 'OTHER RNP4', according to the values defined in ICAO Doc 9613 (PBN Manual). for the attribute requiredNavigationPerformance provide the actual RNP or RNAV value, according to the values defined in ICAO Doc 9613 (PBN Manual).
